CHA156
15.6 inch All-in-one AI-Powered KIOSK
Function introduction
- 15.6 inch Anti-interference touch screen with FHD display.
- Modular bracket for EMV payment devices.
- 5MP HD Camera provide better panoramic A.I. technology.
- High speed 2D scanner ensure smooth operation experience.
- Built-in 3" printer adaptable and convenient installation.
- Shopping table providing customers a seamless self-checkout experience.
Features
AI-Powered Self-Ordering Kiosks
Charon kiosk enables AI-powered grab-n-go self-checkout. The kiosk allows guests to simply place multiple food items on the kiosk tray all at one time where our Panoramic AI service uses computer vision and AI to scan the items, recognize them and add them to the cart.
15.6" FHD Touch Display
5MP Panoramic AI Camera
High Speed 2D Scanner
Built-in 3" Printer
Technical Specifications
| Features | Details |
|---|---|
| System | |
| Model Number | CHA156W |
| Chipset | Intel® H420E |
| Processor | Intel® Core i5-10400F, 12MB Smart Cache, Up to 4.3Ghz |
| GPU | GeForce® GTX 1650 4GB GDDR6 |
| Memory | Support DDR4-2133/2400/2666/2933MHz, 2 x U-DIMM Slot, Up to 2 x 32GB |
| Storage | 128G/256G/512G M.2 SATA SSD (PCIE SSD Factory Option) |
| OS | Windows 10/11, Ubuntu |
| Display | |
| Type | 15.6" TFT LED Backlight |
| Resolution | 1920 x 1080 |
| Brightness | 350cd/m2 |
| Touchscreen | Projective Capacitive Touch Screen |
| Interface | |
| Display | 1 x HDMI, 1 x VGA |
| USB | 6 x USB3.0, 3 x USB2.0, 1 x External USB2.0 |
| LAN | 2 x RJ45, 1000M Gigabit Ethernet |
| Audio | 1 x Line-Out, 1 x Mic-In |
| Keyboard & Mouse | 1 x PS/2 Connector |
| Power Supply | ATX Power Supply Unit 650W |
| Standard Components | |
| Scanner | 2D Barcode Scanner |
| Printer | 3" Printer with Auto Cutter, 170mm/s |
| Camera | 5MP AF HD USB Camera |
| Physical & Environmental | |
| Operating Temperature | Operating 0~60° |
| Storage Temperature | Storage -35°~75° |
| Dimensions (W x H x D) | 618.62 x 738.71 x 658.09 MM |
| Packing Dimensions (W x H x D) | Main Host: 880 x 395 x 590MM; Base: 750 x 560 x 100MM |
| Packing Weight | Main Host: 27.40KG; Base: 19.40KG |
| Color | Black/White |
| Options & Peripherals | |
| Wifi | 802.11 a/b/g/n Wireless Protocol (2.4Ghz + 5Ghz) |
| Bluetooth | Bluetooth 4.0 |
| Speaker | 1 x 4Ω x 3W Speaker |
| Operating Console Size | (W x D) 460.00 x 356.00MM |
