MINOS MIN101A
10.1" Mini Desktop Android POS
The MINOS POS series features a modern and contemporary design in a compact footprint. With powerful Android performance, a rich I/O interface, and flexible installation methods, it's perfect for space-constrained checkout environments.
Function introduction
- Compact 10.1'' Display:Crisp 1280x800 IPS screen with a 160° viewing angle.
- Flexible Mounting:Standard VESA 75*75mm allows mounting anywhere and everywhere.
- Rich Connectivity:Multiple USB, Serial, and Network ports packed into a tiny chassis.
- Android Core:Powered by the Rockchip RK3568 Quad-Core processor on Android 11.
Miniature Footprint, Maximum Utility
The MINOS MIN101A redefines desktop POS by squeezing enterprise-grade connectivity and a crisp touchscreen into an incredibly small 10.1" form factor.
Space-Saving Design
Perfect for pop-up shops, small counters, and kiosks. Its minimalistic desktop stand keeps your workspace tidy without sacrificing capability.
Complete Connectivity
Despite its size, the MINOS features 4x USB ports, Gigabit Ethernet, an RJ11 serial port, and an RJ12 cash drawer port right on the I/O panel.
Vivid IPS Touch Screen
The 10.1" projective capacitive touch display features a 1280x800 resolution and a 160-degree viewing angle, ensuring crystal-clear visibility from any position.
OS
Android 7 / 11
CPU
Rockchip RK3568
Memory
Up to 4GB RAM DDR3
Main Display
10.1" IPS Capacitive
Technical Specifications
| Features | Details |
|---|---|
| SYSTEM | |
| Model Number | MIN101A |
| Processor | RK3568 ARM Cortex-A55 Quad-Core, 2.0GHz |
| Memory | 2GB / 4GB DDR3 |
| Storage | 16GB / 32GB EMMC |
| OS | Android 7 / Android 11 |
| DISPLAY | |
| Main Display | 10.1 inch IPS Display |
| Resolution | 1280*800 |
| Viewing Angle | 160°(H) ; 160°(V) (CR≥10) |
| Touchscreen | Projective Capacitive Touch Screen |
| INTERFACE | |
| USB | 2*USB2.0, 2*USB3.0 |
| Serial Port | 1*RJ11(RS232) |
| LAN | 1*RJ45 Gigabit Ethernet |
| Cash Drawer Port | 1*RJ12 |
| Power Supply | Input AC 100~240V/50~60hz, Output DC12V/5A |
| PHYSICAL & ENVIRONMENTAL | |
| Operating Temperature | Operating -20°~70° |
| Storage Temperature | Storage -25°~75° |
| Dimensions(W×H×D) | 251x288x49(mm) |
| OPTIONS & PERIPHERALS | |
| Network / Connectivity | IEEE 802.11 b/g/n /ac(2.4Ghz) Bluetooth 4.2 |
| Mounting | VESA 75*75mm standard |
