JAW-D8
8 inch customer display
Function introduction
- 8 inch customer display, improving service quality and customer shopping experience.
- High Brightness TFT-LCD Digital Panel with 450 nits luminance.
- Multiple interfaces: USB2.0 / USB3.0 / HDMI for flexible connection.
- Powered by USB only (5V), easy and convenient installation.
- High resolution up to 1024x600 for clear and vivid display.
Features
JAW-D8
8 inch customer display with high brightness TFT-LCD panel, USB powered (5V) and USB2.0 / USB3.0 / HDMI interfaces for flexible connection to your POS system.
Technical Specifications
| Features | Details |
|---|---|
| Specification | |
| Model | JAW-D8 |
| Technical Solution | Display link/FL 2000 |
| Interface | USB2.0/USB3.0/HDMI |
| Resolution | 800*480 / 1024*600 |
| Power Supply | Only USB 5V |
| Display Area | 154(H)*86(V)mm (16:9) |
| Display Type | High Brightness TFT-LCD (Digital-Panel) |
| Back Light | LED |
| White Luminance | 450 Nits |
| Response Time | 25ms |
| Viewing Angle | 350° (Horizontal), 60° (Vertical) |
| Temperature | Operating: -20°C - 45°C |
| MTBF | 5000 hours |
| Weight | 1112g |
